Print Method - Dye-sublimation / resin thermal transfer
Resolution - 300 dpi (11.8 dots/mm) continuous tone
Colors - Up to 16.7 million / 256 shades per pixel
Print Ribbon Options - Options include easy-to-use ribbon with disposable ribbon cartridge (EZ) and more economical and eco-friendly refill ribbon for cartridge (ECO).
Both EZ and ECO:
- Resin black (standard), 1000 prints
EZ only:
- Full-color with resin black and overlay panel, YMCKO*, 250 prints
- Full-color half-panel with resin black and overlay panel, YMCKO*, 350 prints
- Full-color with two resin black panels and overlay panel, YMCKOK*, 200 prints
- Full-color with fluorescing, resin black and overlay panel, YMCFKO*, 200 prints
- Full-color with fluorescing, two resin black panels and overlay panel, YMCFKOK*, 175 prints
- Resin black and overlay panel, KO*, 500 prints
- Dye-sublimation black and overlay panel, BO*, 500 prints
- Resin green, blue, red, white, silver, gold, 1000 prints
- Resin silver and gold metallic, 500 prints
- Rewrite technology - no ribbon is required
Print Speed** - 6 seconds per card (K*); 8 seconds per card (KO*); 16 seconds per card (YMCKO*); 24 seconds per card (YMCKOK*)
Accepted Standard Card Sizes - CR-80 (3.375˝ L x 2.125˝ W / 85.6 mm L x 54 mm W); CR-79 adhesive back (3.313˝ L x 2.063˝ W / 84.1 mm L x 52.4 mm W)
Print Area - CR-80 edge-to-edge (3.36˝ L x 2.11˝ W / 85.3 mm L x 53.7 mm W); CR-79 (3.3˝ L x 2.04˝ W / 83.8 mm L x 51.8 mm W)
Accepted Card Thickness - Print only: .009˝ - .040˝ / 9 mil - 40 mil / .229 mm - 1.016 mm; print / lamination: .030˝ - .040˝ / 30 mil - 40 mil / .762 mm - 1.02 mm
Accepted Card Types - PVC or polyester cards with polished PVC finish; monochrome resin required for 100% polyester cards; optical memory cards with PVC finish; rewrite
Input Hopper Card Capacity - Dual-input card hopper (200 cards)
Output Hopper Card Capacity - Up to 100 cards (.030˝ / .762 mm)
Reject Hopper Card Capacity - Up to 100 cards (.030˝ / .762 mm) - same-side input / output card hopper or lamination module required
Card Cleaning - Card cleaning roller integrated into ribbon cartridge; cleaning roller is automatically replaced with each ribbon change
Memory - 32 MB RAM
Software Drivers - Windows® XP / Windows Vista® (32 bit & 64 bit) / Server 2003 & 2008 / Windows® 7 / Windows® 8 (32 bit & 64 bit)/ MAC OS X 10.5/10.6/10.7/10.8 / Linux***
Interface - USB 2.0 and Ethernet with internal print server
Operating Temperature - 65° to 80° F / 18° to 27° C
Humidity - 20–80% non-condensing
Dimensions
- Single-sided printer: 9.8˝ H x 18.1˝ W x 9.2˝ D / 249 mm H x 460 mm W x 234 mm D
- Dual-sided printer: 9.8˝ H x 18.7˝ W x 9.2˝ D / 249 mm H x 475 mm W x 234 mm D
- Printer + lam: 18.9˝ H x 18.7˝ W x 9.2˝ D / 480 mm H x 475 mm W x 234 mm D
Weight - Single-sided printer: 9lbs / 4.1 Kg; dual-sided printer: 11lbs / 5 Kg; printer + lam: 20 lbs / 9.1 Kg
Agency Listings - Safety: UL 60950-2, CSA C22.2 (60950-07), and CE; EMC: FCC Class A, CE (EN 55022 Class A, EN 55024), CCC, BSMI, KC
Environmental Features - All configurations without a lamination module are ENERGY STAR® qualified printers
Supply Voltage - 100-240Vac, 50-60Hz, 1.6 Amps max
Supply Frequency - 50 Hz / 60 Hz
Warranty Printer – three years; printhead – three years, unlimited pass with UltraCard®
Encoding Options - Supported smart card and magnetic stripe technologies: 125 kHz (HID Prox) reader; 13.56 MHz (iCLASS® Standard/SE/SR/Seos, MIFARE Classic®, MIFARE Plus®, MIFARE DESFire®, MIFARE DESFire® EV1, ISO 14443 A/B, ISO 15693) read/write encoder; contact smart card encoder reads from and writes to all ISO7816 1/2/3/4 memory and microprocessor smart cards (T=0, T=1) as well as synchronous cards; ISO magnetic stripe encoding, dual high- and low-coercivity, tracks 1, 2 and 3
Supported Access Control Credential Programming - iCLASS® Standard/SE/SR/Seos, MIFARE Classic™, MIFARE DESFire® EV1, HID Prox
Options -Single wire ethernet and USB 2.0 interface for inline printing and encoding (note: single wire Ethernet encoding is only available for iCLASS®, MIFARE®, and contact smart card encoding); dual-sided printing module; same-side input/output card hopper; smart card encoding modules (contact/contactless); magnetic stripe encoding module; printer cleaning kit; secure proprietary consumables system
Software - Swift ID™ embedded badging application, FARGO Workbench™ diagnostic utility with Color Assist™ spot-color matching
Display - User friendly, SmartScreen™ graphical display
Printer Security - Printer access password protected
* Indicates the ribbon type and the number of ribbon panels printed where Y=yellow, M=magenta, C=cyan, K=resin black, O=overlay, B=dye sublimation black.
** Print speed indicates an approximate print speed and is measured from the time a card drops into the output hopper to the time the next card drops into the output hopper. Print speeds do not include encoding time or the time needed for the PC to process the image. Process time is dependent on the size of the file, the CPU, amount of RAM and the amount of available resources at the time of the print.
***Linux versions: Ubuntu 12.04, Debian 7.0, Fedora 18, Mandriva 2011, Red Hat 6.4, Open Suse 12.3
